SRNE 10KW Off Grid Inverter

SRNE 10KW Off-Grid Inverter, a high-efficiency powerhouse designed for seamless performance. With dual MPPT technology reaching up to 99.9% efficiency and supporting 22A PV input current, it accommodates high-power modules. Producing top-notch pure sine wave AC power with a 10kW load capacity, this inverter ensures households’ diverse energy needs are met. Its industrial yet modern design guarantees durability and aesthetics. Installation is easy, and user-friendliness is a priority. The inverter’s versatility shines with a Solar Charger Controller. Supporting up to 200A charging current and Li-ion battery BMS communication. With exclusive Li-ion battery BMS dual activation and a time-slot function for peak-valley tariff savings, the SRNE 10KW Off-Grid Inverter is the all-in-one solution for efficient, reliable, and cost-effective power.
Efficient
Dual MPPT with up to 99.9% efficiency. Up to 22A PV input current perfect for high power modules
Reliable
Outputs high quality pure sine wave AC power. 8-10kW load power to meet the needs of most households
Convenient installation
Industrial design with a modern aesthetic look.Easy to install and simple to use.
Safety
360 degrees of security from hardware to software. EU and North American safety approvals.
Intelligent
Exclusive Li-ion battery BMS dual activation. Time-slot function to save cost with peak-valley tariff.
Communication
Support various brands of battery communication.
Product Features
  • Dual MPPT with up to 99.9% efficiency
  • Up to 22A PV input current perfect for high-power modules
  • Industrial design with a modern aesthetic look
  • Easy to install and simple to use
  • 360 degrees of security from hardware to software
  • Time-slot function to save cost with peak-valley tariff
Specifications
  • Inverter Output:

    • Rated Output Power: 10,000W
    • Max.Peak Power: 20,000W
    • Rated Output Voltage: 230Vac(single-phase L/N/PE )
    • Switch Time: 10ms(typical)
  • Battery:

    • Battery Type: Li-ion / Lead-Acid / User Defined
    • Rated Battery Voltage: 48Vdc
    • Voltage Range: 40~60Vdc
    • Max.MPPT Charging Current: 200A
    • Max.Mains/Generator Charging Current: 120A
    • Max.Hybrid Charging Current: 200A
  • PV Input

    • Num. of MPP Trackers: 2
    • Max.PV array power: 5,500W + 5,500W
    • Max.input current: 22A + 22A
    • Max.Voltage of Open Circuit: 500Vdc + 500Vdc
    • MPPT Voltage Range: 125~425Vdc
